Product details
Part Number: FD-L51
Brand: Panasonic
Description: Panasonic FD-L51 is a Color Detection Fiber Sensor. Official product detail: Fiber [Standard]. Key specifications include Sensing range: 14 to 24 mm 0.511 to 0.945 in; (Note) The sensing range of each fiber is the range for which white non-glossy paper can be detected at the sensitivity for which teaching has been done with a white non-glossy paper (50 x 50 mm 1.969 x 1.969 in ) at the respective rated setting distance and at the 16th grade of tolerance; Material: Fiber core: Acrylic; Sheath: Polyethylene; Fiber head: Polycarbonate; Lens: Polyalylate; Weight: Net weight: 15 g approx; Applicable amplifiers: FZ-11, FZ-11P; Setting distance: 20 mm 0.787 in (fixed); Spot diameter (at setting distance): dia. 5 mm dia. 0.197 in; Allowable bending radius: R25 mm R0.984 in or more; (Note) If the fiber cable is bent at less than R25 mm R0.984 in or less, the detectability may deteriorate; Fiber cable length: 1 m 3.281 ft.
Handling Time: In-stock items ship the same day. Transfer items usually need 3–5 days.
Shipping: UPS, DHL, and USPS. Expedited shipping in as little as 1–2 business days. Contact us for details.
